LPC Approves Plans for Governors Island

East, Ticker | Tuesday, February 7, 2012 | Tom Stoelker.

In a unanimous decision, the Landmarks Preservation Commission approved the first phase of plans by the Trust for Governors Island to restore and revamp the island. The vision includes a paisley-like landscape by West 8 on the terrace in front of McKim, Mead and White designed Liggett Hall. Way-finding by Pentagram and lighting by Susan Tillotson also made the cut. For a detailed breakdown of the designs click here.

(De) and (Re) Construction

As civilization (?) expanded westward, everything had to be built up from scratch. Developing new land, erecting new structures, creating new cities. But this era has long since passed. Even in China, where up to 20 new cities are being built every year, the bubble is about to burst. Construction is increasingly shifting from a practice of creating new built environments, to renovating , repairing, and sometimes just removing the existing structures. And what are we to do with all the existing materials?

Re-using of materials has long been the mantra of our schoolchildren, and many industries have also seen the wisdom of providing for the recycling of the product in its end use. For example, in the US, 95% of “junked” cars are processed for recycling, with about 75% of the car’s manufactured content mostly metals) eventually being recycled for raw material use.

One of the main reasons automobiles could be recycled was due to the nature of metals, and the ability to purify and separate out elements for re-use in their raw state. Construction is not quite so straightforward, since it involves many more materials which are intermixed within the same assembly. Possibly the “cleanest” of materials for construction reuse is concrete. The only problem has always been the removal of rebar, but one solution has been invented by a company in Ohio , who attached a magnet to the excavator bucket, which can be activated as it runs over a pile of crushed concrete to pull out the rebar. The cleaned, crushed concrete can be re-used for roadbed and rebar is fully recyclable. In some areas, this has grown to be a sizeable business, such as Recycled Materials Company, which was launched by the need to demolish and recycle the concrete at the old Stapleton Airport in Denver.

More difficult is the repurposing of all the miscellaneous materials from deconstruction. Here again, there is a business opportunity. Instead of paying to have a building demolished, an owner can hire a deconstruction arm of a non-profit company (such as Habitat Re-Store) to remove the property as a donation to a material re-use store. The owner gets a tax deduction, and the store gets paid for receiving merchandise. They get paid again for selling it. Of course, the cost of removal may exceeds the removal revenue, but even then – Habitat uses volunteers!

Renovation companies are growing. From my experience, the difference between a successful operation and a big junkyard is in the systematic documenting of materials, making this available on the web, and keeping good business practices. Overstuffed, cat-infested warehouses just get more material, tend to hike up their prices to overcome the low sales, and eventually go out of business. It is a business.

One person who has done this well, in the re-use of industrial byproducts and waste for the use in construction and other industries is Damon Carson, of Repurposed Materials. Because the company is selective in the materials they gathers, and can provide a fairly steady supply, it is possible for entrepreneurial ventures like Luxwood to manufacture furniture with the use of reclaimed wood.

The problem in developing a business model in construction which could accommodate the use of repurposed materials is the extra cost of sourcing this material and adjusting the construction process to accommodate for special installation. Such a scenario could be addressed through a “joint venture,” so to speak, with the owner as the scouting party. A scope would need to be developed for acceptable type of materials, and specifications developed to help guide owners choices. The material types might start with reliable local supplies of recycled materials. While this requires a higher degree of organization on the contractor’s part, in order to be more flexible without upsetting the core building process, I see evidence of this trend growing. Not only for homeowners, but also commercial properties – where owners are looking for more unique architecture.

On fifth try, Puck changes finally pass muster

In Detail> Frick Portico Gallery

Davis Brody Bond created a climate-controlled gallery from one of the Frick mansion’s open air loggias.

Paul Rivera

Davis Brody Bond Architects & Planners with Renfro design Group

Balanced on a pedestal at the end of the Frick Collection’s newest gallery, Diana, goddess of the chase, appears to have just leaped back across Fifth Avenue after a little hunting in Central Park. That this late-18th-century statue by Jean-Antoine Houdon was allowed to emerge from storage and strike a pose against an appropriately sylvan backdrop is one of the highlights of a thoughtful renovation led by Davis Brody Bond (DBB).

The Portico Gallery for Decorative Arts and Sculpture, the museum’s first new exhibition space in 35 years, was created from a south-facing loggia running along the Frick mansion’s ample front yard. The project came about when a donor’s gift (an extensive collection of porcelain) required additional display space. DBB and former Frick director Anne Poulet decided to take a cue from the 1914 building’s original architect, Thomas Hastings of the firm Carrère and Hastings, who, just after completing Henry Frick’s main house, immediately began sketching up a proposal for a sculpture gallery addition.

Left to Right: Thomas hastings’ 1916 drawing for a proposed sculpture gallery at The Frick mansion; a plan of the New Gallery with ITS Bluestone Floor; and a section showing DAvis Brody Bond’s new glass curtain wall and ventilation system.  (right). Courtesy the frick collection/DBB

Hastings’ scheme went on hold once the United States entered World War I in 1917 and never came to pass due to Frick’s death in 1919. But almost a century later, that plan to create a sculpture gallery connected to the main house led DBB to consider the disused colonnaded loggia, whose decorative limestone relief carving has been fading due to exposure to corrosive exhaust fumes from Fifth Avenue traffic. Part of the original house, the long and narrow 815-square-foot loggia was accessible from the library, but had long been closed to museum goers.

The new gallery’s southern orientation means copious amounts of sunlight, an issue for paintings but less so for sculpture and ceramics. “We wanted to maintain the character of an outdoor space,” said DBB partner Carl Krebs, whose team specified low-iron glass panels to fill the spaces between the columns. The panels, some of the largest in production at approximately 14 feet by 7 feet by 2 inches, are cantilevered from below, resting in shoes secured 16 inches below the floor. Framed in bronze and set slightly back from the outmost edge of the loggia’s floor, the glass panels defer to the limestone columns, allowing the space to retain its original appearance both from the interior and the exterior.

LEFT TO RIGHT: Illuminated at night, the Gallery becomes a vitrine for sculpture and ceramics; the modernist Curtain Wall defers to the Loggia’s Beaux arts Colonnade; from the Rotunda, Houdon’s Diana The Huntress (1776-1795) overlooks the 815-Square-foot gallery. Paul Rivera

The loggia’s stone paving was too damaged to be saved, but removing it allowed DBB to install power lines and a radiant heating system below for finely tuned climate control. Ventilation of the space was made easy thanks to a series of existing grates running along the floor of the interior wall, where the gallery’s main display cases are mounted. The grates originally allowed air into servant’s quarters in the basement, and DBB took advantage of the subterranean space to install new air ducts. Lantern-style custom lighting fixtures modeled on those found elsewhere in the house hang from the ceiling of a newly insulated roof; a striking bluestone floor replicates the pattern of the early 20th-century paving, running the length of the gallery and culminating in Diana’s oval rotunda.

A Jewel Box for Translucent Treasures

A Jewel Box for Translucent Treasures

Michael Bodycomb/The Frick Collection

White Gold: Highlights From the Arnhold Collection of Meissen Porcelain is the inaugural exhibition in the Frick Collection’s newly enclosed Portico Gallery.

By KEN JOHNSON
Published: December 15, 2011

In light of the glass-box atrium plugged into the J. P. Morgan Library & Museum a few years ago, New York cultural custodians might have been understandably alarmed to learn of plans for architectural intervention at another great institution of Gilded Age ancestry. They need not have worried. The Frick Collection’s transformation of an outdoor colonnade into an indoor exhibition space, now called the Portico Gallery, is as subtly noninvasive as the Morgan’s addition is conspicuously anachronistic.

This is admittedly an unfair comparison: the Frick’s new gallery is not a central thoroughfare but a lateral cul-de-sac that will be used for rotating displays of decorative arts and sculpture. From the outside the only visible change to the portico, which faces south over the Fifth Avenue Garden, are floor-to-ceiling windows, minimally framed in bronze, inserted between the columns.

Though just 815 square feet, the space feels much more expansive and airy than it really is. French doors closing in the small rotunda at the end of the portico look as if they had always been there, and so does a life-size statue of a nude Diana, frozen in midstride on one foot, beautifully modeled in terra cotta between 1776 and 1795 by the French neo-Classical sculptor Jean-Antoine Houdon. She has recently been cleaned and is back on view after a three-year absence. Elevated on a waist-high pedestal, she seems to gaze over the traffic on Fifth Avenue with divine disregard for mere human reality. All this was designed and carried out by the architecture firm Davis Brody Bond.

Read more

Concourse Plaza Hotel and Union League Club receive individual Landmarks status.

NEW YORK CITY LANDMARKS PRESERVATION
COMMISSION
Robert B. Tierney
Chairman
FOR IMMEDIATE RELEASE
Tuesday, Oct. 25, 2011
No. 11-12
GRAND CONCOURSE HISTORIC DISTRICT
AND FOUR INDIVIDUAL LANDMARKS PROTECTED

Another noteworthy building from the earlier stage of the district’s development is the Concourse Plaza Hotel at 900 Grand Concourse between East 161st and 162nd streets. Built in 1923, the same year as nearby Yankee Stadium, the 11-story Colonial Revival style hotel drew such distinguished guests and visitors as Yankees greats Babe Ruth, Roger Maris and Mickey Mantle and presidential candidates Franklin D. Roosevelt, Harry Truman and John F. Kennedy.

“The buildings in the district were so solidly built that they emerged from a period of neglect largely unscathed, and still retain many of the fine architectural details that first attracted residents to the Grand Concourse in the 1920s and 1930s,” said Chairman Tierney. “This is a great day for the Bronx.”

Union League Club, 38 East 37th Street at Park Avenue
The nine-story, brick-faced clubhouse, located at the southwest corner of 37th Street and Park Avenue, was completed in 1931 and combines elements of the 18th century Federal and Georgian styles of architecture. It was designed by (Benjamin Wistar) Morris & (Robert Barnard) O’Connor. Prior to establishing the firm, Morris received a number of significant commissions, including the annex to the Morgan Library, the Cunard Building and the Bank of New York & Trust Company building at 48 Wall St.
Originally located in a former residence on the north side of Union Square in Manhattan, the Union League Club was founded in 1863 to support the United States and the Republican Party. During the Civil War, the club organized the first black regiment in New York State and its members later played a significant role in establishing the Metropolitan Museum of Art. It also was one of the first social clubs in New York City to welcome women.
The club’s current site was assembled by prominent Murray Hill families who wanted to maintain neighborhood’s residential character, and sold the property with restrictions dictating the size of buildings could be constructed there.
The 37th Street façade of the club incorporates a curved, double height entrance pavilion and oversized Palladian style windows, and a central pediment that frames a cartouche with club’s initials. A lintel decorated with four female faces surmounts the wood doors of a second entrance on Park Avenue. Women gained full membership privileges in 1988, and Democrats were permitted to join in 1937.
“After 80 years, the Union League Club remains a stately gem on a tranquil corner of Murray Hill,” said Chairman Tierney.

In Detail> Shepard Hall

The Gothic revival Shepard Hall in Hamilton Heights, built in 1907, has new glass fiber-reinforced concrete decorative trim in place of original terra cotta.

Courtesy Elemental

Designed by George B. Post and completed in 1907, City College’s Shepard Hall is in all probability the most faithful specimen of English Perpendicular Gothic revival architecture in the United States. The first structure to inhabit the institution’s Hamilton Heights campus, it was modeled on a cathedral plan, its main entrance within a bell tower on St. Nicolas Terrace that connects two flanking academic wings and a central great hall for assemblies. Like many of its Gothic predecessors, unfortunately, the building also featured certain flaws that, over time, led to severe deterioration in the building’s fabric and the threat of catastrophic structural collapse.

the team replaced some 70.000 pieces of deteriorated terra cotta (left) with the gfrc product (right), which could be used to mass-produce repetitive decorative elements.

Post constructed the hall primarily from local schist—stone quarried during the excavation of the site—and terra cotta, which makes up the decorative elements. He used the terra cotta, however, structurally, as if it were just another piece of masonry. While terra cotta is very strong under compression, it has almost no tensile properties. As a result, when water infiltrated the walls and as the building swelled and contracted with the changing seasons (it was built without expansion joints), the terra cotta could not handle the stresses as well as the schist, and so it began to crack, break up, and come loose. By 1986, when architecture firm Elemental (then The Stein Partnership) answered an RFP to restore and reconstruct Shepard Hall’s envelope, pieces of terra cotta the size of grapefruits had been falling off the building with regularity for some ten years. Only one third of the original material remained. The rest had been filled in with bricks and stucco.

From the outset, the architects decided that in replacing the terra cotta, they would employ a rain screen system with a light, thin-shell material fulfilling the decorative aspects and a separate material taking on the structural role. The material would also need to be mass-produced in order to meet the reconstruction schedule. Some 70,000 pieces of terra cotta needed replacing, 3,000 of which were completely unique sculptures—allegorical representations of academics, gargoyles and grotesques, and vegetative motifs. The team considered terra cotta, but the material was quickly ruled out since it would have taken decades to produce the needed pieces by the two manufacturers in the country who could do it at all. They settled on reinforced concrete (GFRC), basically a Portland cement with significant chemical variations. It uses only fine-grain aggregate, a small amount of polymer, glass, and carefully controlled sand.

the thin-shell replicas were bolted back to a new masonry structure, with soft joints between the new masonry and original schist.

A sprayed product about 3/4-inch thick, the GFRC offered the possibility of speeding up the fabrication of all of the repetitive pieces and keeping cost down. The sculptural elements took a little more time. Those that remained more or less intact were removed from the building, touched up, and used to form rubber-lined production molds. Those that had vanished were recreated from old photographs or extrapolated from fragments. The GFRC system offered a much higher level of precision than did the original process. To be as faithful as possible to the original, Elemental took care to introduce the imperfections characteristic of terra cotta, including tooling marks, irregularities on flat planes, and slight variations in the “white” color from piece to piece.

The team filled in the structural gaps left by the terra cotta with traditional masonry structure, and bolted each thin-film replica back to the new masonry. This allowed the creation of soft joints between each piece and the existing schist. When taken across an entire elevation, these small, soft joints comprise a de facto expansion-joint system capable of accommodating significant building movement.

In the course of replacing the terra cotta, the architects uncovered a number of other issues that needed attention. The bell tower was discovered to be in a state of structural failure. Steel supports in the existing masonry had corroded to the point of no longer being there. All that was holding it up was the terra cotta, some rubble stone, and a chicken-wire wrapper placed there to keep the gargoyles from falling onto students below. It was completely rebuilt, the cladding removed, a new precast, post-tensioned concrete structure inserted, and then the new thin-film elements attached. Elemental divided the project into ten contract packages, ordered according to severity of need, and tackled them when the budget became available. The firm is now finishing the ninth package. Although not among the gargoyles, the spirit of George B. Post might well sit smiling, twirling his Edwardian whiskers in hearty approval.
